配件料號：
| 型號：3400氣動(dòng)鉚釘槍 | |||
| Designation | Articleno. | Designation | Articleno. |
| PRN811 | Nosepiece | DPN900-030 | O-Ring |
| PRG540-44 | Jaws | DPN900-072 | O-Ring |
| DPN276-001 | Jaw Guide | DPN276-039 | Tube Seal Case |
| DPN276-002 | Pulling Head | FAN276-040 | Tube Assembly |
| DPN276-003 | Jaw Guide Lock | DPN276-043 | Sleeve Lock Nut |
| DPN276-004 | Nose Housing | DPN276-044 | Bottom Plate |
| DPN900-059 | O-Ring | DPN276-045 | J Valve Cap |
| DPN276-005 | Nose Housing Nut | DPN900-073 | O-Ring |
| DPN276-006 | Jaw Pusher | DPN900-012 | O-Ring |
| DPN900-060 | O-Ring | DPN900-074 | O-Ring |
| DPN901-019 | Jaw Pusher Spring | DPN900-035 | O-Ring |
| DPN901-020 | Spring | DPN276-046 | J Valve Rod |
| DPN276-007 | Pulling Head Joint | DPN239-069 | EXT Silencer |
| DPN276-008 | Hydraulic Piston | DPN900-075 | O-Ring |
| DPN276-009 | Spacer Pipe | DPN900-076 | O-Ring |
| DPN276-010 | Housing Adapter | DPN276-047 | J Valve Fitting |
| DPN900-061 | O-Ring | DPN276-048 | H.L Fitting |
| DPN276-011 | Rod Seal Case | DPN276-049 | Air Tube |
| DPN908-015 | Scraper | DPN239-120 | Fitting |
| DPN900-062 | O-Ring | FAN239-074 | S Valve Case Assembly |
| DPN908-021 | B.U-Ring | DPN900-014 | O-Ring |
| DPN908-022 | Penta Seal | DPN902-001 | Retaining Ring |
| DPN900-063 | O-Ring | DPN239-078 | S Valve Rod |
| DPN908-023 | B.U-Ring | DPN906-001 | Button Head Cap Screw |
| DPN900-064 | O-Ring | DPN239-150 | Trigger |
| DPN276-012 | Handle Upper | DPN900-015 | O-Ring |
| DPN901-021 | Return Spring | DPN239-083 | Connect Tube |
| DPN900-065 | O-Ring | DPN276-050 | Handle R,L |
| DPN276-013 | MCS Valve Case | DPN907-001 | Socket Head Cap Screw |
| DPN276-014 | MCS Valve Rod | DPN239-086 | Hexagon Nut |
| DPN900-066 | O-Ring | DPN276-051 | Plug |
| DPN901-022 | Spring | DPN276-052 | Chamber |
| DPN276-015 | End Cap Adapter | DPN907-009 | Socket Head Cap Screw |
| DPN276-016 | MCS Cap Front | DPN276-063 | Hook |
| DPN276-017 | Slider | FAN276-055 | Collector (Assembly) |
| DPN900-067 | O-Ring | DPN276-056 | Collector Lock Collar |
| DPN276-019 | MCS Cap Tail | DPN900-077 | O-Ring |
| DPN900-068 | O-Ring | DPN276-057 | Collector Lock |
| DPN276-018 | Slider Pusher | DPN903-001 | Flat Head Cap Screw |
| DPN900-069 | O-Ring | DPN276-058 | Collector Body |
| DPN276-020 | End Cap | DPN276-059 | Collector Silencer |
| DPN276-061 | Collar | DPN276-060 | Collector End Cap |
| DPN276-021 | Collar Screw | DPN276-062 | Collector End |
| DPN276-023 | Ejector Guide | DPN239-152 | Collector End Nut |
| DPN900-013 | O-Ring | DPN900-079 | O-Ring |
| DPN907-002 | Socket Head Cap Screw | DPN276-080 | Deflector Adapter |
| DPN276-024 | End Cap Plate | DPN900-022 | O-Ring |
| FAN276-022 | Ejector (Assembly) | PRG510-56 | Deflector |
| DPN900-045 | O-Ring | DPN276-053 | R Joint Spacer |
| DPN239-047 | Fill Screw | DPN276-076 | R Joint |
| DPN900-007 | O-Ring | DPN276-054 | R Joint Adapter |
| DPN900-070 | O-Ring | DPN276-078 | OS Slider |
| DPN900-036 | O-Ring | DPN900-078 | O-Ring |
| DPN276-028 | Sleeve Upper | DPN276-077 | OS Joint |
| DPN276-029 | Restrictor | DPN900-080 | O-Ring |
| DPN902-002 | Retaining Ring | PRG540-46 | Jaws |
| DPN276-030 | Upper Plate | PRN414 | Nosepiece 4 size |
| DPN276-031 | Sleeve Lower | PRN514 | Nosepiece 5 size |
| DPN276-085 | Pan Head Screw | PRN614 | Nosepiece 6 size |
| FAN276-033 | Handle Lower Assembly | FAN276-064 | Jaw Pusher (Assembly) |
| FAN276-036 | Air Piston Assembly | DPN239-139 | HS Screw Key 4mm |
| DPN900-071 | O-Ring | FAN276-154 | Air Line Assembly |
| FAN275-022 | EXT Valve (Assembly) | DPN276-155 | Air Line Fitting |
| DPN275-025 | EXT Valve Head | DPN276-156 | Hose Female Fitting |
| DPN901-008 | EXT Valve Spring | DPN276-157 | Air Tube |
| DPN275-024 | EXT Valve Case | DPN276-158 | Ear Clamp |
| DPN275-023 | EXT Valve Rod |
